MicroPython 性能测试数据

吃瓜阿阳 2022-11-07 13:32:46

友情提示点击顶部放大镜可以使用站内搜索记住我们的地址 www.hainabaike.com

MicroPython 在不同的硬件上性能测试数据，为选择性能合适的硬件提供参考。

测试的开发板：
micro:bit
PYB Nano
PYBV10
ST Nucleo_F091RC
ST Nucleo_F411RE
STM32L476DISC
STM32F7DISC
ST Nucleo_H743ZI
ESP8266
ESP32 WROVER

MicroPython 版本

microbit

1.9.2

ESP32 Lobo

3.20.20

All other device

1.9.4-479

测试项目

Integer addition 1000,000 times
Float addition 1000,000 times
Integer multiplication 1000,000 times
Float multiplication 1000,000 times
Integer division 1000,000 times
Float division 1000,000 times
1000 digit Pi calculation
5000 digit Pi calculation
100,000 digit Pi calculation

结果

	MCU	Freq	Int Add	Float Add	Int Mul	Float Mul	Int div	Float Div	Pi:1000	Pi:5000	Pi:100000
microbit	nRF51822	16M	61.89	78.03	71.59	81.60	67.95	106.87	10.98	–	–
Nucleo_F411	STM32F411	96M	5.86	13.96	6.07	14.02	6.07	14.07	1.25	19.03	–
PYBV10	STM32F405	168M	3.44	7.93	3.56	7.97	3.56	8.13	0.67	10.8	–
Nucleo_L432KC	STM32LM32	32M	20.86	46.35	21.49	46.55	21.95	46.71	2.60	49.44	–
STM32L476DISC	STM32L476	80M	8.59	18.34	8.99	18.42	8.93	18.49	1.37	21.45	–
STM32F7DISC	STM32F746	192M	1.93	5.16	2.45	5.08	2.12	5.39	0.21	5.42	4276.47
Nucleo_H743	STM32H743	400M	0.86	1.96	0.94	1.98	0.91	2.07	0.11	4.66	1004.32
ESP8266	ESP8266	80M	15.55	18.34	17.96	18.92	16.96	21.46	2.09	40.22	–
ESP32	ESP32	240M	2.61	4.42	2.79	4.42	2.72	4.66	0.57	8.41	–
ESP32 psRAM	ESP32	240M	3.37	7.96	3.55	17.88	15.25	8.32	0.67	18.01	12394.50
K210	K210C		8.19	8.76	8.23	8.74	7.75	8.76	0.12	2.82	1480.96

'''
  File:     benchmarks.py
  Descript: benchmark test for different microcontroller
  Author:   Shao ziyang
  Data:     2018-Octo-25
  Version:  1.0
'''
import time
import machine
import gc

def pi(places=100):
  # 3 + 3*(1/24) + 3*(1/24)*(9/80) + 3*(1/24)*(9/80)*(25/168)
  # The numerators 1, 9, 25, ... are given by (2x + 1) ^ 2
  # The denominators 24, 80, 168 are given by (16x^2 -24x + 8)
  extra = 8
  one = 10 ** (places+extra)
  t, c, n, na, d, da = 3*one, 3*one, 1, 0, 0, 24

  while t > 1:
    n, na, d, da = n+na, na+8, d+da, da+32
    t = t * n // d
    c += t
  return c // (10 ** extra)

def pi_test(n = 5000):
    t1 = time.ticks_ms()
    t = pi(n)
    t2 = time.ticks_ms()
    r = time.ticks_diff(t2, t1)/1000
    print('  Pi', n, 'digit calculation: ', r, 's')
    return '%.2f'%r

def int_add_test(n = 1000000, a = 12345, b = 56789):
    t1 = time.ticks_ms()
    sum = 0
    for i in range(n):
        sum = a + b
    t2 = time.ticks_ms()
    r = time.ticks_diff(t2, t1)/1000
    print('  Integer Add test', n, 'times: ', r, 's')
    return '%.2f'%r

def float_add_test(n=1000000, a = 1234.5678, b = 5678.1234):
    t1 = time.ticks_ms()
    sum = 0
    for i in range(n):
        sum = a + b
    t2 = time.ticks_ms()
    r = time.ticks_diff(t2, t1)/1000
    print('  Float Add test', n, 'times:', r, 's')
    return '%.2f'%r

def int_mul_test(n=1000000, a = 12345, b = 56789):
    t1 = time.ticks_ms()
    sum = 0
    for i in range(n):
        sum = a * b
    t2 = time.ticks_ms()
    r = time.ticks_diff(t2, t1)/1000
    print('  Integer Mul test', n, 'times: ', r, 's')
    return '%.2f'%r

def float_mul_test(n=1000000, a = 1234.5678, b = 5678.1234):
    t1 = time.ticks_ms()
    sum = 0
    for i in range(n):
        sum = a * b
    t2 = time.ticks_ms()
    r = time.ticks_diff(t2, t1)/1000
    print('  Float Mul test', n, 'times: ', r, 's')
    return '%.2f'%r

def int_div_test(n=1000000, a = 123456, b = 567):
    t1 = time.ticks_ms()
    sum = 0
    for i in range(n):
        sum = a // b
    t2 = time.ticks_ms()
    r = time.ticks_diff(t2, t1)/1000
    print('  Integer Div test', n, 'times: ', r, 's')
    return '%.2f'%r

def float_div_test(n=1000000, a = 12345.678, b = 56.789):
    t1 = time.ticks_ms()
    sum = 0
    for i in range(n):
        sum = a / b
    t2 = time.ticks_ms()
    r = time.ticks_diff(t2, t1)/1000
    print('  Float Div test', n, 'times: ', r, 's')
    return '%.2f'%r

def mem():
    r = gc.mem_free()
    print('free memory:', r)

print('Speed test')
try:
    print('System freq: {:.1f} MHz'.format(machine.freq()[0]/1000000))
except:
    print('System freq: {:.1f} MHz'.format(machine.freq()/1000000))

print('
Calcaulate integer addition')
gc.collect()
mem()
d1 = int_add_test()
d2 = int_add_test()
d3 = int_add_test()
r_int_add =  min(d1, d2, d3)
print('Integer addition test result: ', r_int_add, 's')
mem()

print('
Calcaulate float addition')
gc.collect()
mem()
d1 = float_add_test()
d2 = float_add_test()
d3 = float_add_test()
r_float_add = min(d1, d2, d3)
print('Float addition test result: ', r_float_add, 's')
mem()

print('
Calcaulate integer multiplication')
gc.collect()
mem()
d1 = int_mul_test()
d2 = int_mul_test()
d3 = int_mul_test()
r_int_mul = min(d1, d2, d3)
print('Integer multiplication test result: ', r_int_mul, 's')
mem()

print('
Calcaulate float multiplication')
gc.collect()
mem()
d1 = float_mul_test()
d2 = float_mul_test()
d3 = float_mul_test()
r_float_mul = min(d1, d2, d3)
print('Float multiplication test result: ', r_float_mul, 's')
mem()

print('
Calcaulate integer division')
gc.collect()
mem()
d1 = int_div_test()
d2 = int_div_test()
d3 = int_div_test()
r_int_div = min(d1, d2, d3)
print('Integer division test result: ', r_int_div, 's')
mem()

print('
Calcaulate float division')
gc.collect()
mem()
d1 = float_div_test()
d2 = float_div_test()
d3 = float_div_test()
r_float_div = min(d1, d2, d3)
print('Float division test result: ', r_float_div, 's')
mem()

print('
Calcaulate Pi 1000 digit')
gc.collect()
mem()
try:
    d1 = pi_test(1000)
    d2 = pi_test(1000)
    d3 = pi_test(1000)
    r_pi_1000 = min(d1, d2, d3)
    print('1000 digit Pi calculation result: ', r_pi_1000, 's')
    mem()
except:
    r_pi_1000 = None
    print('  calculation error')

print('
Calcaulate Pi 5000 digit')
gc.collect()
mem()
try:
    d1 = pi_test(5000)
    d2 = pi_test(5000)
    d3 = pi_test(5000)
    r_pi_5000 = min(d1, d2, d3)
    print('5000 digit Pi calculation result: ', r_pi_5000, 's')
    mem()
except:
    r_pi_5000 = None
    print('  calculation error')

print('
Calcaulate Pi 100,000 digit')
gc.collect()
mem()
try:
    d1 = pi_test(100000)
    d2 = pi_test(100000)
    d3 = pi_test(100000)
    r_pi_100000 = min(d1, d2, d3)
    print('100000 digit Pi calculation result: ', r_pi_100000, 's')
    mem()
except:
    r_pi_100000 = None
    print('  calculation error')

print('Test result:')
print('  Integer addition test result: ', r_int_add, 's')
print('  Float addition test result: ', r_float_add, 's')
print('  Integer multiplication test result: ', r_int_mul, 's')
print('  Float multiplication test result: ', r_float_mul, 's')
print('  Integer division test result: ', r_int_div, 's')
print('  Float division test result: ', r_float_div, 's')
if r_pi_1000:
    print('  1000 digit Pi calculation result: ', r_pi_1000, 's')
if r_pi_5000:
    print('  5000 digit Pi calculation result: ', r_pi_5000, 's')
if r_pi_100000:
    print('  100000 digit Pi calculation result: ', r_pi_100000, 's')

这份数据来自 Shao ziyang 老师的分享。
https://github.com/shaoziyang/micropython_benchmarks
